Hydro Royal Pool Heat Pumps

Hydro Royal Pool Heat Pumps HR Series

  • Proudly built in the USA.

  • Units are suitable for salt and fresh water applications.

  • Titanium heat exchanger to avoid corrosion and coated components for salty environment applications.

  • Special cabinet material protects your unit from the weather making it possible to install outdoors if necessary.

    Ultra quiet operation at 56 db. R410-A Refrigerant.

  • Digital display to accurate monitor water temperature.

  • Best Warranty in the market. Excellent customer service.


Hydro Royal is  dedicated to developing and manufacturing the finest heat pumps to conserve energy and protect the environment. With a quarter of a century of production of heat pumps, Hydro Royal has set the standard. Hydro Royal's test facility rigidly checks each heat pump during every step of manufacturing. All units are run-tested to assure efficiency and reliability. Quality is assured through Hydro Royal's years of experience, research & development and  continuous testing.

Hydro Royal Pool Heat Pump HR Series in stock! FREE SHIPPING!

Ships out same day if order placed before noon EST. Models available in 60 Hertz, Single Phase and 220 Volts. Please contact us for 3 Phase option or 50 Hertz.

Manufacturer's Warranty valid in Continental USA. All others please contact us for warranty information.

For other size options or chiller options please contact us.

Hydro Royal Pool heat pump Model Specifications:




For other size options or chiller options please contact us. Model Specifications

HR 90 Heat Only

*Contact us if you need a chiller option.

Warranty: 5 years parts / 2 years labor  Lifetime on titanium heat exchanger

BTU: 90,000 * COP: 6.3

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU: 84,000 * COP: 5.8

AHRI Testing 50/63/80: BTU: 56,000 * COP: 4.0

No minimum tank size needed

HR 110 Heat Only

*Contact us if you need a chiller option.

 Warranty: 5 years parts / 2 years labor  Lifetime on titanium heat exchanger



BTU: 110,000 * COP: 6.4

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU: 99,000 * COP 6.0

AHRI Testing 50/63/80: BTU: 66,000 * COP:4.1

No minimum tank size needed

HR 125 Heat Only

*Contact us if you need a chiller option.

Warranty: 5 years parts / 2 years labor  Lifetime on titanium heat exchanger

BTU: 120,000 * COP: 6.4

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU: 109,000* COP:5.9

AHRI Testing 50/63/80: BTU: 74,000 * COP: 4.1

No minimum tank size needed

HR 125HC Heat & Cool

*Contact us if you need a chiller option.

Warranty: 5 years parts / 2 years labor  Lifetime on titanium heat exchanger

BTU: 120,000 * COP: 6.4

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU: 109,000* COP:5.9

AHRI Testing 50/63/80: BTU: 74,000 * COP: 4.1

No minimum tank size needed

HR 150 Heat Only

*Contact us if you need a chiller option.

Warranty: 5 years parts / 2 years labor Lifetime on titanium heat exchanger

BTU: 136,000 * COP: 6.

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU:124,000 * COP:5.4

AHRI Testing 50/63/80: BTU: 85,000 * COP: 4.0

No minimum tank size needed

HR 150 Heat & Cool

*Contact us if you need a chiller option.

Warranty: 5 years parts / 2 years labor Lifetime on titanium heat exchanger

BTU: 136,000 * COP: 6.

Outside AHRI Testing Standard 1160

AHRI Testing 80/63/80: BTU:124,000 * COP:5.4

AHRI Testing 50/63/80: BTU: 85,000 * COP: 4.0

No minimum tank size needed


Hydro Royal TITANIUM FEATURES AND BENEFITS
Pool Heat Pump Features



    CABINET
    • Visually attractive durable design. Will never rust or corrode.
    • U.V. resistant polymeric materials that will never rust or corrode.
    • One piece raised top features a molded fan venturi that is at the top of the evaporator coil. This Allows for maximum airflow over 100% of the coil surface, increasing efficiency even on the coldest days.
    • Unique 4 inch pedestal base keeps evaporator clean and out of harms way.
    • High strength plastic coil guard protects fins from impact and adds to the appearance of the unit.
    SET IT & FORGET IT - DISPLAY Our products offer one touch programming and the latest operating features available, including state of the art micro-computer controls
  • Powerful microcomputer control.
  • Push button operation.
  • Large LED display.
  • Dual pool/spa programmable thermostat.
  • Displays temperature in Fahrenheit or Celsius.
  • With an easy-to-use keypad, all you have to do is program the desired temperature onto the control panel. Hydro Royal pool heat pumps will do the rest.

    QUIET PERFORMANCE

    Our new fan design improves air flow and reduces noise by more than 50%! A molded fan venturi that begins at the top of the evaporator. This allows maximum air flow over 100% of the coil surface, increasing efficiency even on the coldest of days.

    EVAPORATOR

    The coated energy efficient evaporator features internally rifled tubing and an enhanced aluminum fin design. Our double row coils have maximum surface area boosting efficiency and performance. High strength plastic coil guard protects the unit from impact and adds to the appearance of the unit.

    TITANIUM HEAT EXCHANGER

    The heat exchanger features a lifetime warranty. Turbo-Titanium Strength All Hydro Royal pool heat pumps come with Turbotec Titanium Heat Exchanger for the maximum efficiency and performance for heat exchange. Our rifled design assures maximum transfer of heat to your pool water. The tight rifling allows for less titanium in the inner core of the exchanger, resulting in a very efficient, light weight unit. Features Turbo Guard: "Turbo" reflects the enhanced surface turbo action of the water and Freon in the heat exchanger and "guard" reflects the nature of the fusion blended alloy material used to guard against or prevent corrosion of the heat exchanger. Designed and developed for the best performance and highest efficiency in the industry. Enhanced surface tubing design.

    SCROLL COMPRESSOR

    Designed for excellence in performance, silence and endurance. Quietest and most reliable compressors in the industry.

    OPERATING COSTS
    A Hydro Royal pool heat pumps offer dramatic savings in operating costs. Cost per 100,000 BTU Input:
  • Super-Sized evaporator coil
  • This is where efficiency begins
  • Largest in it’s class (20 square feet of wrap-around coil)
  • Higher performance in colder weather
  • Titanium Turbo Heat Exchanger
  • Lifetime Warranty
  • Impervious to erosion and corrosion
  • Full flow (no need to bypass)
  • Helium (He) Tested
  • Refrigerant system tested with the second smallest element
  • Finds leaks 100 times smaller than our competitors
  • Virtually eliminates refrigerant loss – No recharging!
  • Quiet scroll compressor
  • 10-year limited warranty
  • The quietest of all compressors
  • More efficient and no maintenance
  • State of the art manufacturing
  • Each component individually stamped with the serial number
  • Computerized tracking system when service is required
  • Remote control ready
  • Compatible with all pool/spa automation controllers
  • Hurricane guard
  • UV resistant rust proof polymer
  • Tight mesh configuration for optimal protection
  • Diagnostic LCD Readout
  • Programmed in real words – No codes to learn
  • Self diagnostic LCD will display a fault if problems occur
  • Simple to use dual thermostat for pool and spa Control lockout
  • Keeps renters or children from changing settings
  • ABS Plastic cabinet
  • UV inhibited / High – strength
  • Easy to clean. No rust!

Hydro Royal pool heat pump Installation Manual




Installation and Owners Manual

Troubleshooting Guide




If you have reason to believe that your heater is not functioning properly, review the troubleshooting guide to eliminate the following:


Frequently Asked Questions




How do Hydro Royal pool heat pumps compare with other heat pumps?

With over 30 years of heat pump heater design experience, Hydro Royal Pool Heat Pumps are built to outperform the competition. Advanced micro-computer technology and exclusive design features result in 25% more heating performance than other leading heat pumps. Unlike most other heat pump heaters, which use off-the-shelf components, Hydro Royal uses components specifically designed for optimum performance. This means higher efficiency and lower operating costs than competitive heat pumps. All Hydro Royal Pool Heat Pump heaters are equipped with our Turboguard heat exchanger for long life and high performance. In addition, with its unique micro-computer technology, Hydro Royal pool heat pumps operate most cost-effectively throughout the full range of operating conditions, significantly outperforming the competition in the critical 40-60 degree air temperature range.

What does the Hydro Royal titanium heat exchanger offer?

The turbo titanium heat exchanger is designed to be used in Hydro Royal pool heat pump heaters. The name reflects (2) key aspects of the heat exchanger's design. "Turbo" reflects the enhanced surface turbo action of the water and freon in the heat exchanger and the nature of the fusion blended alloy material used to guard against or prevent corrosion of the heat exchanger.

What is enhanced surface tubing?

Enhanced surface tubing is a twisted tube as opposed to standard round tube. It has two major advantages over standard round tube as follows:

  • 3-4 times the surface area over a given length versus standard round tube (more surface area equals more heat transfer and a more compact design). More heat transfer equals more efficiency which equals lower operating costs for the owner.
  • Turbulating action of the water as it swirls around the twisted tube (water simply passes over round tube in a straight line). The turbulating action of the water increases heat transfer and acts as a self cleaning mechanism, eliminating scale and corrosion on the surface of the tube. The net result is significantly lower operating costs.

Titanium Advantages
  • Designed and developed for the best performance and highest efficiency in the industry
  • Enhanced surface tubing design
  • Long lasting with A LIFETIME heat exchanger warranty to back it up
  • Better than copper...all the benefits without the negatives associated with copper
  • The next generation of heat exchangers


What is 24 hour auto heat?

24 hour auto heat is a feature that efficiently maintains your desired temperature 24 hours a day. It eliminates the need for an old time clock, replacing it with its own integrated filter/pump controller. The system divides your programmed filter pump run time into six (6) equal periods, this allows the Hydro Royal pool heat pump to sample the water temperature and add heat if needed keeping your desired water temperature precisely where you want it.



Warranty Information





We invite you to contact us for more information, advice and help. At heatpumpsuppliers.com we understand that your aqua cultural heat pump application will be unique and that it will need to be tailored to your specific needs. We  will work in constant direct contact with the factory engineers to help you design the best possible system for your application. We are ready to assist you.

Koi breeders learn more about aquaculture heat pump

call us now1 888 205 7766
